Ca_Varminter

Here is some more help with your Rapid if need it!!
There also is a full PDF of this post at the end!!

Here is the Pdf to the post..
http://photos.imageevent.com/scl_electronics/gun/air/Disassembly%20of%20the%20Rapid%20Bolt.pdf

A little more help to all the Rabid Rapid Owner out There!!

Stuart
_________________

mcmike · Posted: Wed Oct 15, 2008 9:57 pm Post subject:

Stuart,

As usual, a great technical analysis. Thanks so much for taking the time to post these Rapid "self help" instructions.

You ROCK my friend,

Mike
_________________
"Talent hits a target no one else can hit, Genius hits a target no one else can see." Arthur Schopenhauer

220swift · Posted: Thu Oct 16, 2008 2:36 am Post subject:

Very well done
nothing like a good barrel and probe change with bolt adjustment
to get your rapid going

Laughing

swift

_________________
Swift
rapid technician
tuning mild to wild
custom parts made to order
swiftairgunparts@sbcglobal.net
http://swiftairgunswork.blogspot.com/

Ca_Varminter · Posted: Thu Oct 16, 2008 2:57 am Post subject:

Thanks Mike!
I am glad My little tech post are helping my fellow rapid owners out there in the trenches!!
Mosh

Thanks Swift for the kind words too!!
You know what you are missing in your barrel/probe photo spread....
You need a flea shooter... .177 barrel and probe for comparison!!
Headphones

Thanks again guys!!
It makes it worth all the effort!
Bottle Of Beer

Stuart
_________________

airwolf · Posted: Thu Oct 16, 2008 10:51 am Post subject:

Superb as always Stuart. Mosh

Will you come and post it on our site? Very Happy

if its not there already and we can make a sticky with it. Bottle Of Beer
